SCHNEIDER ATS01 SERIES SOFT STARTER
Provides smooth starting for your pumps, fans, compressors and machinery & Progressive start limits the starting and stopping noise of motors
Model Available:
ATS01N206/209/212/222/232QN
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
RM872.87 – RM1,837.12
-
Warranty included
-
User menu available for download
Payment Methods:
-
Pick up from any Exerlon Power HQ branch
To pick up today
Free
-
Pick up from any Exerlon Power Penang branch
To pick up today
Free
-
Pick up from any Exerlon Power Johor branch
To pick up today
Free
-
Pick up from any Exerlon Power Ipoh branch
To pick up today
Free
-
Courier delivery
Our courier will deliver to the specified address
2-3 Days
Charges will be applied
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty included
-
User menu available for download
Range of product: Altistart 01
Device short name: ATS01
product or component type: Soft starter
product destination: Asynchronous motors
Product specific application: Simple machine
Network number of phases: 3 phases
[Us] rated supply voltage: 380…415 V – 10…10 %
Motor power kW: 2.2KW, 4KW, 5.5KW. 11KW,15KW ,3 phases at 380…415 V
Utilisation category: AC-53B conforming to EN/IEC 60947-4-2
Current consumption: 110 A at nominal load
Type of start: Start with voltage ramp
Power dissipation in W: 124.5 W in transient state / 4.5 W at full load and at end of starting
Model Available:
– ATS01N206QN
– ATS01N209QN
– ATS01N212QN
– ATS01N222QN
– ATS01N232QN
Specification
Overview
| Weight | N/A |
|---|---|
| Dimensions | N/A |
| Function Available |
Integrated Bypass ,With Heat Sink |
| Utilisation Category |
AC-53B conforming to EN/IEC 60947-4-2 |
General
| Range of Product |
Altistart 01 |
|---|---|
| Device Short Name |
ATS01 |
| Product or Component Type |
Soft Starter |
| Brand |
Schneider |
